Nch 60V 50A, DFNWB3×3-8L, SGT Power MOSFET
| Part Number | Status | VGS V |
ID A |
VGS(TH) V |
RDS(mΩ)@VGS 10V Typ |
RDS(mΩ)@VGS 10V Max |
RDS(mΩ)@VGS 4.5V Typ |
RDS(mΩ)@VGS 4.5V Max |
Package |
|---|---|---|---|---|---|---|---|---|---|
| CJAE9R0SN06AL | Active | ±20 | 50 | 1.3~2.5 | 7 | 9 | 10 | 13 | DFNWB3x3-8L |
| Part Number | Package Type | Component Weight(g) | Marking | Packing Info | MSL |
|---|---|---|---|---|---|
| CJAE9R0SN06AL | DFNWB3x3-8L | - | 9R0SN06AL | Tape&Reel:5Kpcs/Reel | MSL1 |
